SNES Basic DIP42 4MB

$4.00

Simple SNES board capable of games up to 4MB (32 Megabit)

Discount per Quantity

Quantity 10 -49 50 -249 250 +
Price $3.75 $3.50 $3.25

Out of stock

Description

SNES Basic DIP42 4MB

The SNES Basic DIP42 4MB is a homebrew or reproduction board that supports LoROM and HiROM games up to 4MB (32 Megabit) with a 42 Pin EPROM.

Component List

ROM – 27C160/27C322 or compatible. (Not Carried)

Lockout Chip – SuperCIC Key (12F629 programmed with Super CIC Key) (HERE)

Address Multiplexing Chip x2 – 74LS257 (HERE)

C1 – 22uf 16V Capacitor (HERE)

C2,C3,C4 – 0.1uf 50V Capacitor (HERE)

Instructions/Tutorials

Build instructions/tutorials aren’t available at this time. If you are uncomfortable or new to building your own cartridges please wait for tutorials to become available.

Additional information

Weight 0.0380 lbs
Dimensions 4.2 × 2 × 0.055 in
Color

Black
